GB1205PKV1-8AY
Data Sheet
Attribute
Description
Manufacturer Part Number
GB1205PKV1-8AY
Manufacturer
Description
Fan: DC; blower; 12VDC; 50x50x20mm; 9.68m3/h; 35dB
Manufacturer Lead Time
Not specified
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| DC Fan Type | Blower | |
| DC Fan Bearing Type | ||
| Voltage Rating | 12VDC | |
| Air Flow | 5.7 CFM (0.161m³/min) | |
| Static Pressure | 0.660 in H2O (164.4 Pa) | |
| Noise | 35 dB(A) | |
| Power | 1.50W | |
| RPM | 5200 RPM | |
| Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) | |
| Termination | 2 Wire Leads | |
| Size / Dimension | Square - 50mm L x 50mm H x 20mm W |
Description
Measures resistance at forward current Blower for LED or diode evaluation. Supports high-level output current indicated as 5.7 CFM (0.161m³/min). Peak Vce(on) at Vge 0.660 in H2O (164.4 Pa) for transistor parameters.
