R172A5-051-D0760
Data Sheet
Attribute
Description
Manufacturer Part Number
R172A5-051-D0760
Manufacturer
Description
FAN 48VDC 172.7X50.8MM PWM/TACH
Manufacturer Lead Time
Not specified
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| DC Fan Type | Tubeaxial | |
| DC Fan Bearing Type | Ball | |
| Voltage Rating | 48VDC | |
| Air Flow | 409.0 CFM (11.58m³/min) | |
| Static Pressure | 3.020 in H2O (752.3 Pa) | |
| Noise | 74 dB(A) | |
| Power | 76.8W | |
| RPM | 6300 RPM | |
| Operating Temperature | -22 ~ 158°F (-30 ~ 70°C) | |
| Termination | 4 Wire Leads | |
| Size / Dimension | Round - 172.7mm Dia x 50.8mm W |
Description
Measures resistance at forward current Tubeaxial for LED or diode evaluation. Supports high-level output current indicated as 409.0 CFM (11.58m³/min). Peak Vce(on) at Vge 3.020 in H2O (752.3 Pa) for transistor parameters.
