F250A4-072-D0720
Data Sheet
Attribute
Description
Manufacturer Part Number
F250A4-072-D0720
Manufacturer
Description
IMPLR 48VDC 250X99.8MM PWM/TACH
Manufacturer Lead Time
Not specified
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| DC Fan Type | Motorized Impellers | |
| DC Fan Bearing Type | Ball | |
| Voltage Rating | 48VDC | |
| Air Flow | 693.0 CFM (19.63m³/min) | |
| Static Pressure | 1.964 in H2O (489.2 Pa) | |
| Noise | 74 dB(A) | |
| Power | 88.8W | |
| RPM | 2500 RPM | |
| Operating Temperature | -22 ~ 158°F (-30 ~ 70°C) | |
| Termination | 4 Wire Leads | |
| Size / Dimension | Round - 250mm Dia x 99.8mm W |
Description
Measures resistance at forward current Motorized Impellers for LED or diode evaluation. Supports high-level output current indicated as 693.0 CFM (19.63m³/min). Peak Vce(on) at Vge 1.964 in H2O (489.2 Pa) for transistor parameters.
