CLS-PC11A125S00R
Data Sheet
Attribute
Description
Manufacturer Part Number
CLS-PC11A125S00R
Manufacturer
Description
SWITCH PUSH SPST-NO 3A 125V
Manufacturer Lead Time
Not specified
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Type | Standard, Illuminated | |
| Circuit | SPST-NO | |
| Switch Function | Off-Mom | |
| Current Rating | 3A (AC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | - | |
| Actuator Type | Round, Button | |
| Color - Actuator/Cap | Red | |
| Illumination Type, Color | LED, Red | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Panel Mount, Snap-In | |
| Termination Style | Solder Lug | |
| Ingress Protection | - | |
| Panel Cutout Dimensions | Circular - 16.00mm Dia |
Description
Measures resistance at forward current Off-Mom for LED or diode evaluation. Utilizes Red type of illumination for ideal lighting.
