Attribute
Description
Manufacturer Part Number
R-531.2DA
Manufacturer
Description
DC - DC Converters,
1,
1.2V,
3A,
3.6W,
Through Hole,...
Manufacturer Lead Time
Not specified
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Type | Non-Isolated PoL Module | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 4.5V | |
| Voltage - Input (Max) | 18V | |
| Voltage - Output 1 | 1.2V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 3A | |
| Power (Watts) - Manufacture Series | 3.6W | |
| Voltage - Isolation | - | |
| Mounting Type | Through Hole, Right Angle | |
| Package / Case | 12-SIP Module | |
| Size / Dimension | 1.27 L x 0.59 W x 0.36 H (32.2mm x 15.0mm x 9.1mm) | |
| Operating Temperature | -40°C ~ 85°C | |
| Efficiency | 0.85 |
Description
Measures resistance at forward current 1 for LED or diode evaluation. Peak Vce(on) at Vge 0.85 for transistor parameters.
