CSD75211W1723
Data Sheet
Attribute
Description
Manufacturer Part Number
CSD75211W1723
Manufacturer
Description
MOSFET 2P-CH 20V 4.5A 12DSBGA
Note :
GST will not be applied to orders shipping outside of India
Stock: 2580
Distributor: 3
Lead Time: Not specified
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 65.98 | ₹ 65.98 |
| 10 | ₹ 65.98 | ₹ 659.80 |
| 100 | ₹ 60.49 | ₹ 6,049.00 |
| 500 | ₹ 60.49 | ₹ 30,245.00 |
| 1000 | ₹ 55.85 | ₹ 55,850.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| FET Type | 2 P-Channel (Dual) | |
| Drain to Source Voltage (Vdss) | 20V | |
| Current - Continuous Drain (Id) @ 25°C | 4.5A | |
| Rds On (Max) @ Id, Vgs | 40 mOhm @ 2A, 4.5V | |
| Vgs(th) (Max) @ Id | 1.1V @ 250µA | |
| Gate Charge (Qg) @ Vgs | 5.9nC @ 4.5V | |
| Input Capacitance (Ciss) @ Vds | 600pF @ 10V | |
| Power - Max | 1.5W | |
| Mounting Type | Surface Mount | |
| Package / Case | 12-UFBGA, DSBGA |
Description
Measures resistance at forward current 2 P-Channel (Dual) for LED or diode evaluation. Peak Rds(on) at Id 40 mOhm @ 2A, 4.5V for MOSFET efficiency.
