MTP50P03HDLG
Data Sheet
Attribute
Description
Manufacturer Part Number
MTP50P03HDLG
Manufacturer
Description
Transistor: P-MOSFET; unipolar; 30V; 50A; 125W; TO
Manufacturer Lead Time
Not specified
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| FET Type | MOSFET P-Channel, Metal Oxide | |
| Drain to Source Voltage (Vdss) | 30V | |
| Current - Continuous Drain (Id) @ 25°C | 50A (Tc) | |
| Rds On (Max) @ Id, Vgs | 25 mOhm @ 25A, 5V | |
| Vgs(th) (Max) @ Id | 2V @ 250µA | |
| Gate Charge (Qg) @ Vgs | 100nC @ 5V | |
| Input Capacitance (Ciss) @ Vds | 4900pF @ 25V | |
| Power - Max | 125W | |
| Mounting Type | Through Hole | |
| Package / Case | TO-220-3 |
Description
Measures resistance at forward current MOSFET P-Channel, Metal Oxide for LED or diode evaluation. Peak Rds(on) at Id 25 mOhm @ 25A, 5V for MOSFET efficiency.
