Attribute
Description
Manufacturer Part Number
IRF7665S2TR1PBF
Manufacturer
Description
Single N-Channel 100 V 2.4 W 8.3 nC Digital Audio Mosfet Sur...
Manufacturer Lead Time
Not specified
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| FET Type | MOSFET N-Channel, Metal Oxide | |
| Drain to Source Voltage (Vdss) | 100V | |
| Current - Continuous Drain (Id) @ 25°C | 4.1A (Ta), 14.4A (Tc) | |
| Rds On (Max) @ Id, Vgs | 62 mOhm @ 8.9A, 10V | |
| Vgs(th) (Max) @ Id | 5V @ 25µA | |
| Gate Charge (Qg) @ Vgs | 13nC @ 10V | |
| Input Capacitance (Ciss) @ Vds | 515pF @ 25V | |
| Power - Max | 2.4W | |
| Mounting Type | Surface Mount | |
| Package / Case | - |
Description
Measures resistance at forward current MOSFET N-Channel, Metal Oxide for LED or diode evaluation. Peak Rds(on) at Id 62 mOhm @ 8.9A, 10V for MOSFET efficiency.
