EB50101S2-000U-999
Data Sheet
Attribute
Description
Manufacturer Part Number
EB50101S2-000U-999
Manufacturer
Description
Fan: DC; axial; 12VDC; 50x50x10mm; 18.6m3/h; 26dBA
Manufacturer Lead Time
Not specified
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| DC Fan Type | Tubeaxial | |
| DC Fan Bearing Type | Sleeve | |
| Voltage Rating | 12VDC | |
| Air Flow | 11.0 CFM (0.311m³/min) | |
| Static Pressure | 0.110 in H2O (27.4 Pa) | |
| Noise | 26 dB(A) | |
| Power | 1.44W | |
| RPM | 4300 RPM | |
| Operating Temperature | - | |
| Termination | 2 Wire Leads | |
| Size / Dimension | Square - 50mm L x 50mm H x 10mm W |
Description
Measures resistance at forward current Tubeaxial for LED or diode evaluation. Supports high-level output current indicated as 11.0 CFM (0.311m³/min). Peak Vce(on) at Vge 0.110 in H2O (27.4 Pa) for transistor parameters.
