1204KL-01W-B49-B00
Data Sheet
Attribute
Description
Manufacturer Part Number
1204KL-01W-B49-B00
Manufacturer
Description
FAN DC AXIAL 5V 30X10 LOCK RTR
Manufacturer Lead Time
Not specified
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| DC Fan Type | Tubeaxial | |
| DC Fan Bearing Type | Ball | |
| Voltage Rating | 5VDC | |
| Air Flow | 3.2 CFM (0.09m³/min) | |
| Static Pressure | 0.148 in H2O (37.0 Pa) | |
| Noise | 23 dB | |
| Power | 0.70W | |
| RPM | 9000 RPM | |
| Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) | |
| Termination | 3 Wire Leads | |
| Size / Dimension | Square - 30mm L x 30mm H x 10mm W |
Description
Measures resistance at forward current Tubeaxial for LED or diode evaluation. Supports high-level output current indicated as 3.2 CFM (0.09m³/min). Peak Vce(on) at Vge 0.148 in H2O (37.0 Pa) for transistor parameters.
