AFB0512HD-F00
Data Sheet
Attribute
Description
Manufacturer Part Number
AFB0512HD-F00
Manufacturer
Description
DC Fans,
Tubeaxial,
12VDC
Note :
GST will not be applied to orders shipping outside of India
Stock: 246
Distributor: 2
Lead Time: Not specified
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 871.50 | ₹ 871.50 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| DC Fan Type | Tubeaxial | |
| DC Fan Bearing Type | Ball | |
| Voltage Rating | 12VDC | |
| Air Flow | 15.8 CFM (0.447m³/min) | |
| Static Pressure | 0.182 in H2O (45.3 Pa) | |
| Noise | 33 dB(A) | |
| Power | 1.20W | |
| RPM | 5600 RPM | |
| Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) | |
| Termination | 3 Wire Leads | |
| Size / Dimension | Square - 50mm L x 50mm H x 20mm W |
Description
Measures resistance at forward current Tubeaxial for LED or diode evaluation. Supports high-level output current indicated as 15.8 CFM (0.447m³/min). Peak Vce(on) at Vge 0.182 in H2O (45.3 Pa) for transistor parameters.
