TL1105DF250Q
Data Sheet
Attribute
Description
Manufacturer Part Number
TL1105DF250Q
Manufacturer
Description
TL1105 Series SPST 2.5 N Round Button PC Through Hole Tactil...
Note :
GST will not be applied to orders shipping outside of India
Stock: 14560
Distributor: 1
Authorized
Lead Time: 3 Working Days
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 10.95 | ₹ 10.95 |
Stock: 7686
Distributor: 2
Lead Time: Not specified
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 14.25 | ₹ 14.25 |
Stock: 1
Distributor: 3
Lead Time: Not specified
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 20.64 | ₹ 20.64 |
| 10 | ₹ 19.12 | ₹ 191.20 |
| 50 | ₹ 16.57 | ₹ 828.50 |
| 100 | ₹ 12.50 | ₹ 1,250.00 |
| 500 | ₹ 11.08 | ₹ 5,540.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Circuit | SPST-NO | |
| Switch Function | Off-Mom | |
| Contact Rating @ Voltage | 0.05A @ 12VDC | |
| Actuator Type | Standard | |
| Mounting Type | Through Hole | |
| Actuator Height off PCB, from Pins | 13.00mm | |
| Actuator Orientation | Top Actuated | |
| Termination Style | PC Pin | |
| Outline | 6.00mm x 6.00mm | |
| Illumination | Non-Illuminated | |
| Illumination Voltage (Nominal) | - | |
| Illumination Type, Color | - | |
| Operating Force | 250gf | |
| Ingress Protection | - |
Description
Keeps a distance of 13.00mm from the PCB surface. Measures resistance at forward current Off-Mom for LED or diode evaluation.
