PTS125VK85
Data Sheet
Attribute
Description
Manufacturer Part Number
PTS125VK85
Manufacturer
Description
SWITCH TACTILE SPST-NO 0.05A 12V
Manufacturer Lead Time
Not specified
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Circuit | SPST-NO | |
| Switch Function | Off-Mom | |
| Contact Rating @ Voltage | 0.05A @ 12VDC | |
| Actuator Type | Plunger for Cap | |
| Mounting Type | Through Hole, Right Angle | |
| Actuator Height off PCB, from Pins | 8.50mm | |
| Actuator Orientation | Side Actuated | |
| Termination Style | PC Pin | |
| Outline | 12.00mm x 12.00mm | |
| Illumination | Non-Illuminated | |
| Illumination Voltage (Nominal) | - | |
| Illumination Type, Color | - | |
| Operating Force | 260gf | |
| Ingress Protection | - |
Description
Keeps a distance of 8.50mm from the PCB surface. Measures resistance at forward current Off-Mom for LED or diode evaluation.
