B123J11ZQ22M
Data Sheet
Attribute
Description
Manufacturer Part Number
B123J11ZQ22M
Manufacturer
Description
SWITCH ROCKER SPDT 6A 125V
Manufacturer Lead Time
Not specified
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Circuit | SPDT | |
| Switch Function | On-On | |
| Current Rating | 6A (AC/DC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 28V | |
| Actuator Style | Concave (Standard V) | |
| Color - Actuator/Cap | Black | |
| Actuator Marking | No Marking | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Panel Mount, Snap-In | |
| Termination Style | Solder Lug | |
| Ingress Protection | - | |
| Panel Cutout Dimensions | Rectangular - 19.20mm x 11.91mm |
Description
Measures resistance at forward current On-On for LED or diode evaluation. Utilizes Black type of illumination for ideal lighting.
