Attribute
Description
Manufacturer Part Number
PTH12010WAS
Manufacturer
Description
MODULE PIP 1.2-5.5V 12A SMD10DIP
Manufacturer Lead Time
53 weeks
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Type | Non-Isolated PoL Module | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 10.8V | |
| Voltage - Input (Max) | 13.2V | |
| Voltage - Output 1 | 1.2 ~ 5.5 V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 12A | |
| Power (Watts) - Manufacture Series | 66W | |
| Voltage - Isolation | - | |
| Mounting Type | Surface Mount | |
| Package / Case | 10-SMD Module | |
| Size / Dimension | 1.37 L x 0.62 W x 0.38 H (34.8mm x 15.7mm x 9.7mm) | |
| Operating Temperature | -40°C ~ 85°C | |
| Efficiency | 0.94 |
Description
Measures resistance at forward current 1 for LED or diode evaluation. Peak Vce(on) at Vge 0.94 for transistor parameters.
