PTH04T260WAZ
Data Sheet
Attribute
Description
Manufacturer Part Number
PTH04T260WAZ
Manufacturer
Description
Other power management ICs
Manufacturer Lead Time
53 weeks
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Type | Non-Isolated PoL Module | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 2.2V | |
| Voltage - Input (Max) | 5.5V | |
| Voltage - Output 1 | 0.69 ~ 3.6 V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 3A | |
| Power (Watts) - Manufacture Series | 11W | |
| Voltage - Isolation | - | |
| Mounting Type | Surface Mount | |
| Package / Case | 10-SMD Module | |
| Size / Dimension | 0.75 L x 0.62 W x 0.34 H (19.1mm x 15.7mm x 8.6mm) | |
| Operating Temperature | -40°C ~ 85°C | |
| Efficiency | 0.95 |
Description
Measures resistance at forward current 1 for LED or diode evaluation. Peak Vce(on) at Vge 0.95 for transistor parameters.
