UIQ48T20120-NDABG
Data Sheet
Attribute
Description
Manufacturer Part Number
UIQ48T20120-NDABG
Manufacturer
Description
DC/DC CONVERTER 12V 240W
Manufacturer Lead Time
Not specified
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Type | Isolated Module | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 18V | |
| Voltage - Input (Max) | 75V | |
| Voltage - Output 1 | 12V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 20A | |
| Power (Watts) - Manufacture Series | 240W | |
| Voltage - Isolation | 2.25kV (2250V) | |
| Mounting Type | Through Hole | |
| Package / Case | 8-DIP Module, 1/4 Brick | |
| Size / Dimension | 2.30 L x 1.45 W x 0.50 H (58.4mm x 36.8mm x 12.7mm | |
| Operating Temperature | -40°C ~ 85°C | |
| Efficiency | 0.925 |
Description
Measures resistance at forward current 1 for LED or diode evaluation. Peak Vce(on) at Vge 0.925 for transistor parameters.
