TPCF8302(TE85L,F,M
Data Sheet
Attribute
Description
Manufacturer Part Number
TPCF8302(TE85L,F,M
Manufacturer
Description
MOSFET 2P-CH 20V 3A VS-8
Manufacturer Lead Time
Not specified
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| FET Type | 2 P-Channel (Dual) | |
| Drain to Source Voltage (Vdss) | 20V | |
| Current - Continuous Drain (Id) @ 25°C | 3A | |
| Rds On (Max) @ Id, Vgs | 59 mOhm @ 1.5A, 4.5V | |
| Vgs(th) (Max) @ Id | 1.2V @ 200µA | |
| Gate Charge (Qg) @ Vgs | 11nC @ 5V | |
| Input Capacitance (Ciss) @ Vds | 800pF @ 10V | |
| Power - Max | 530mW | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-SMD, Flat Lead |
Description
Measures resistance at forward current 2 P-Channel (Dual) for LED or diode evaluation. Peak Rds(on) at Id 59 mOhm @ 1.5A, 4.5V for MOSFET efficiency.
