FDMS86300
Data Sheet
Attribute
Description
Manufacturer Part Number
FDMS86300
Manufacturer
Description
MOSFET,
N CH,
80V,
80A,...
Note :
GST will not be applied to orders shipping outside of India
Stock: 2996
Distributor: 2
Lead Time: Not specified
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 174.00 | ₹ 174.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| FET Type | MOSFET N-Channel, Metal Oxide | |
| Drain to Source Voltage (Vdss) | 80V | |
| Current - Continuous Drain (Id) @ 25°C | 19A (Ta), 80A (Tc) | |
| Rds On (Max) @ Id, Vgs | 3.9 mOhm @ 19A, 10V | |
| Vgs(th) (Max) @ Id | 4.5V @ 250µA | |
| Gate Charge (Qg) @ Vgs | 86nC @ 10V | |
| Input Capacitance (Ciss) @ Vds | 7082pF @ 40V | |
| Power - Max | 2.5W | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-PowerTDFN |
Description
Measures resistance at forward current MOSFET N-Channel, Metal Oxide for LED or diode evaluation. Peak Rds(on) at Id 3.9 mOhm @ 19A, 10V for MOSFET efficiency.
